8103-3-8 – Pipe Fittings

8103-3-8 – Pipe Fittings – Male Connector – Pipe Socket to Male Straight Thread

Print Icon Print Download Icon Download PDF

Specification

  • CPV-O-Seal: H759
  • Derbyshire Marine Catalog No: MP303
  • B: 2-5/8''
  • F: 3/8''
  • G: 15/32''
  • Hex C: 1-5/8''
  • Hex D: 1-5/8''
  • Ips A In: 1/2''
  • Plp Attributes: ips_a_in
  • Thread Size E: 3/4"-16

Specification Table

CPV-O-SealH759
Derbyshire Marine Catalog NoMP303
B2-5/8''
F3/8''
G15/32''
Hex C1-5/8''
Hex D1-5/8''
Ips A In1/2''
Plp Attributesips_a_in
Thread Size E3/4"-16
