3H-8788-10

3H-8788-10 – High Pressure Hoses

Print Icon Print Download Icon Download PDF

Specification

  • Approx Od In: 1.031
  • Construction: A. Inner Tube: Oil And Fuel Resistant Synthetic Compound. B. Reinforcement: Sizes 4-12 Are Double Wire Braided. Size 16 Is Triple Wire Braided. C. Outer Cover: Oil And Fuel Resistant Synt
  • Hose Id: 0.563
  • Hose Size: 5/8
  • Identification: Black Cover With Yellow Lay Line Indicating The Specification Pin
  • Max Operating Pressure PSI: 3
  • Mil Spec: Mil-Dtl-8788
  • Min Bend Radius : 6.500
  • Min Burst Pressure: 12
  • NSN No.: 4720-00-554-8087
  • Operating Systems: A. Severe Vibrating And Flexing. B. Resistant To Engine Oil And Cleaning Solvent Externally. C. Internal And External Temperatures From -65°F To +160°F. D. Internal Fluids
  • Proof Test Pressure Psi: 6
  • Weight Lbs Per Ft: 0.563

Specification Table

Approx Od In1.031
ConstructionA. Inner Tube: Oil And Fuel Resistant Synthetic Compound. B. Reinforcement: Sizes 4-12 Are Double Wire Braided. Size 16 Is Triple Wire Braided. C. Outer Cover: Oil And Fuel Resistant Synt
Hose Id0.563
Hose Size5/8
IdentificationBlack Cover With Yellow Lay Line Indicating The Specification Pin
Max Operating Pressure PSI3
Mil SpecMil-Dtl-8788
Min Bend Radius 6.500
Min Burst Pressure12
NSN No.4720-00-554-8087
Operating SystemsA. Severe Vibrating And Flexing. B. Resistant To Engine Oil And Cleaning Solvent Externally. C. Internal And External Temperatures From -65°F To +160°F. D. Internal Fluids
Proof Test Pressure Psi6
Weight Lbs Per Ft0.563
