( MIL-DTL-24787/1, Type F, Group IV, Class V, 150lb, End Fitting - Straight )

Description:

Equal to Hydrasearch P/N 375-190767,
Use with the following hose: HS4265, HS4224, 2562, 150901

Specification

  • Part Number: 375-190767-40-40
  • IPS Size: 2.5
  • No. of Bolt Holes: 4
  • A: 5.16
  • D: 2.34
  • E: 2.06
  • J: 7.00
  • K: 3.28
  • L: 5.50
  • M: .75
  • N: .50
  • Q: 3.90
  • S: 2.24
  • V: 3.69
  • Est. Wt. (lbs.): 10.81

Specification Table

Part Number375-190767-40-40
IPS Size2.5
No. of Bolt Holes4
A5.16
D2.34
E2.06
J7.00
K3.28
L5.50
M.75
N.50
Q3.90
S2.24
V3.69
Est. Wt. (lbs.)10.81

Specification Image

375-190767

Components Table

DescriptionReq’d per Ass’yBase No.32-404040-484856-6464Material
Swivel Flange1188-74021-32-4040-4040-4848-4856-6464-64Aluminum. Bronze
Nipple1188-4112-404040-4848-4856-6464-64Aluminum. Bronze
Socket Assy.14-1205-404048486464Monel
Grip Segment44-1205-1-404048486464Monel
Ring14-21004-404048486464Monel
Band14-21023-404048486464Monel
