HS1488
4-191301-HS-2
( MIL-DTL-24787/3, Type CL, Group VIII, End Fitting - 90° )
Description:
Equal to product P/N P/N 4-191301,
Use with the following hose:
Synthetic yarn & wire reinforced hoses i.a.w. MIL-DTL-24136/3, MIL-DTL-24135/10/12, e.g. HS P/N 2580
Type / Group / Class
Related Products
Specification
Dimensions Table
Components Table
| Description | Req’d per Ass’y | Base No. | 3/4-16 | 1-20 | 1.25-24 | 1.5-32 | Material |
|---|---|---|---|---|---|---|---|
| Elbow | 1 | 4-186301- | 3/4-16 | 1-20 | 1.25-24 | 1.5-32 | Copper Nickel & Monel |
| Socket | 1 | 4-1212- | 16 | 20 | 24 | 32 | Monel |
